7" 30X 2.0MP IP High Speed PTZ Camera
- 2.0MP 1/2.8" CMOS Sensor
- 30X Motorized Zoom Auto Focus ICR Lens
- 2D + 3D DNR / BLC / 150M IR Range
Description
| CB-33X-A1520 | |
| Sensor | 2.0MP 1/2.8" CMOS Sensor (MStar SSC30KD + SONY IMX 307) |
| Frame Rate | 2MP / 1080P (1920*1080) @30fps |
| Minimum Illumination | Color: 0.01 Lux @ F1.6(AGC ON), B/W: 0Lux @ F1.6(AGC ON) |
| Lens | 30X (5-150mm) Motorized Zoom Auto Focus ICR Lens |
| Focus Mode | Auto / Semi-Auto / Manual |
| Electronics Shutter | AES / 1/25S - 1/10,000S, Support Day and Night Electronic Shutter Adjustment |
| Aperture Value | F1.6 ~ F3.0 |
| View of Angle | H: Wide 65.5º/Tele 5.0º, V: Wide 39.1º/Tele 4.4º |
| Close-Up Distance | 1.5-150 Meter |
| Day / Night | Auto, Dual IR-Cut filter |
| Auto Control IR LED | PWM |
| Ambient Light Detection | IR Illumination on 1-100 Grades Adjustable |
| IR Range | 4pcs 42 MIL Array IR for 50M + 4 Laser Led for 150M, Max. IR Distance: 150M |
| White Balance | AWB (Auto / Manual / Lock) |
| Gain Control | AGC |
| BLC | BLC: On / Off |
| DNR | 2D + 3D DNR |
| HDR / WDR | Support HDR / DWDR |
| Smart Image Enhance | Strong Light Suppression, Face Overexposure Prevention, Smart Infrared |
| S/N Ratio | ≥60 dB |
| Video Encoding | H.265+, H.265 Main Profile / H.264 High Profile / H.264 Main Profile / H.264 Baseline Profile |
| Video Compression | H.265 / H.264 / M-JPEG |
| Max. Resolution | Main Stream: 1920*1080@25/30fps Sub Stream: 1280*720/704*576/640*480/352*288@25/30fps Third Stream: 640*480/352*288@25/30fps |
| Bit Rate | 32Kbps~10Mpbs |
| Smart Code | Smart H.265 / H.264, Dynamic Code Stream, Fixed Code Stream, Low Code Stream |
| Audio Encoding | G.711 / G.711A (64Kbps) |
| Audio | 1 Audio Input/1 Audio Output (Build in Mic and Support 3W Speaker) |
| LAN Ports | RJ45*1, 10Base-T/100Base-TX |
| Network Protocol | DDNS, DNS, DHCP, FTP, HTTP, HTTPS, IPv4, IPV6, NTP, PPPoE, RTP, RTCP, RTMP, RTSP, SMTP, SNMP, TCP/IP, UPnP |
| Protocol | ONVIF2.4 / CGI / HIKVISION |
| Communication Protocol | Pelco-D, Pelco-P |
| Baud Rate | 1200 / 2400 / 4800 / 9600bps (Default:9600bps) |
| Software Control | IE, CAMPRO VMS Client, CAMPRO NVSS Client, CAMPRO NVMS Client |
| Browser | IE8+, Chrome31+, Firefox30+, Safari8.0+ |
| Mobile View | Support Windows, Symbian, iPhone Platform Smart phone |
| Preview Videos | Max. 3 Users Preview at the same time |
| Storage (Optional) | Support 256GB Micro SD Card Storage and Support Scheduled Video Storage |
| Snapshot | Remote Timing Snapshot, Mobile View Images Snapshot |
| Motion Detection | Intelligent Multiple Detection Zones (Max. 4 Zones, Sensitivity: 1-100 level) |
| Humanoid Detection | Humanoid Detection Record, Snapshot, Alarm Output, Tracking |
| Alarm Linkage | E-mail Alert and Upload Snapshot to FTP, Relay Out, Mobile Phone App |
| Smart Detection | Humanoid Detection, Area Intrusion Detection, Cross Border Detection, Entering Area Detection, Fast Motion Detection, Motion Detection, Video Occlusion Detection |
| Smart Tracking | Fixed Point Tracking, Cruise Tracking |
| Smart Recording | Motion Detection Recording, Humanoid Detection Recording, Timing Recording |
| Tracking Solution | Humanoid Coordinate Positioning |
| Horizontal Rotation Range | 360° |
| Horizontal Control Speed | 0.1-200°/S |
| Horizontal Preset Speed | 0.1-300°/S |
| Tilt Control Speed | 0.1-200°/S |
| Horizontal Rotation Speed | 0.02 - 400° |
| Tilt Rotation Speed | 0.02 - 45°/s |
| A-B Scan | User Programmable |
| A-B Scan Speed | 0-10 Levels Setting Available |
| Dwell Preset | 2-30s Interval Available |
| Preset points | 256 |
| Guard Tours | 3 Groups |
| Guard Points | Max. 32 Points, Dwell Time user Selectable |
| PWR On Action | Memory / Pattern 1 / Tour 1 / 360° Scan / A-B Scan / Preset 1-8 / None |
| Communication Mode | RS-485 (+/-) |
| Communication Protocol | Pelco-D |
| Default: 9600bps | |
| Operating Temp. | -30° - 40℃ |
| Storage Temp. | -20° - 60℃ |
| Humidity | ≤95% Non Condensing |
| Power | DC12V ≤ 4A |
| Power Consumption | ≤ 20W |
| Lighting Protection | Transient Voltage 6000V, Anti-Surge |
| Weight | 3.5KG (N.W.) / 5KG (G.W) |
| Related Validation | IP67 |
| Certification | CE / FCC / RoHS |
