7" 30X 2.0MP AHD High Speed PTZ Camera
- 2.0MP 1/2.9" CMOS Sensor
- 30X Motorized Zoom Auto Focus ICR Lens
- 2D + 3D DNR / BLC / 150M IR Range
Description
| CB-33X-1520 | |
| Sensor | 2.0MP 1/2.9" CMOS Sensor (SONY IMX 291 CMOS) |
| Video Output | AHD / CVI / TVI / VCBS (1Vp-p 75Ω) |
| Scanning Mode | Scanning Mode Progressive Scanning |
| Frame Rate | 2MP / 1080P (1920*1080) @30fps |
| Minimum Illumination | Color: 0.01 Lux @ F1.6(AGC ON), B/W: 0Lux @ F1.6(AGC ON) |
| Lens | 30X (5-150mm) Motorized Zoom Auto Focus ICR Lens |
| Focus Mode | Auto / Semi-Auto / Manual |
| Electronics Shutter | AES / 1/25S - 1/10,000S, Support Day and Night Electronic Shutter Adjustment |
| Aperture Value | F1.6 ~ F3.0 |
| View of Angle | WIDE 50°, TELE 3.1° |
| Close-Up Distance | 1.5-150 Meter |
| Day / Night | Auto, Dual IR-Cut filter, Day / Night Mode: Color / Black and White / Auto |
| Auto Control IR LED | PWM |
| IR Range | 4pcs 42 MIL Array IR for 50M + 4 Laser Led for 150M, Max. IR Distance: 150M |
| White Balance | AWB (Auto / Manual / Lock) |
| Gain Control | AGC |
| BLC | BLC: On / Off |
| DNR | 2D + 3D DNR |
| Privacy Mask | Support, Up to 4 Areas |
| S/N Ratio | ≥60 dB |
| Anti-Flash | 50Hz / 60Hz / Off |
| Mirror Function | Support |
| Image Flip | Support |
| Horizontal Rotation Range | 360° |
| Tilt Rotation Range | 90° |
| Horizontal Rotation Speed | 0.02 - 400° |
| Tilt Rotation Speed | 0.02 - 45°/s |
| A-B Scan | User Programmable |
| A-B Scan Speed | 0-10 Levels Setting Available |
| Dwell Preset | 2-30s Interval Available |
| Preset points | 256 |
| Guard Tours | 3 Groups |
| Guard Points | Max. 32 Points, Dwell Time user Selectable |
| PWR On Action | Memory / Pattern 1 / Tour 1 / 360° Scan / A-B Scan / Preset 1-8 / None |
| Communication Mode | RS-485 (+/-) |
| Communication Protocol | Pelco-D |
| Baud Rate | Default: 9600bps |
| Operating Temp. | -30° - 40℃ |
| Storage Temp. | -20° - 60℃ |
| Humidity | ≤95% Non Condensing |
| Power | DC12V ≤ 4A |
| Power Consumption | ≤ 20W |
| Lighting Protection | Transient Voltage 6000V, Anti-Surge |
| Weight | 3.5KG (N.W.) / 5KG (G.W) |
| Related Validation | IP67 |
| Certification | CE / FCC / RoHS |
