Description
| TTA111VT | TTA111VR | |
| Video Format | NTSC / PAL | X |
| Video Input | BNC x 1 (1 Vp-p, 75 Ohm) | X |
| Video Output | 4 pin removable terminal x 1(100 Ohm, 3 Vp-p) | 1 Vp-p, 75 Ohms (BNC Connector) |
| Switch | Slide switch x 1 | X |
| Power Supply | DC 12V 500mA | |
| Video Gain Adjusting | X | 1 0~300M 2 300~600M 3 600~900M 4 900~1200M 5 1200~1500M |
| Recommended Cable | X | CAT5 UTP Cable 4 pair (24AWG) |
| Power Consumption | 75 mA (Max) | 40mA (Max) |
| Temperature | Operation: 0 ~ 55°C , Storage: -20 ~ 85°C, Humidity: up to 95% | |
| Dimension | 43.2 x 45.2 x 74 mm | |
| Weight | 55 g | 60g |
| Certification | CE / FCC / RoHS | |
