7" 36X 5.0MP HD IP 150M IR PTZ
Back to list

7" 36X 5.0MP HD IP 150M IR PTZ

  • 5.0MP 1/2.8" CMOS Sensor ( Hi3516E V300 + SONY IMX335)
  • Day & Night / IR-Cut / 1920P (2592x1944) / 36X Optical Zoom
  • Onvif / OSD / IP66 / 8pcs IR LED/ Support 3D Location
Description
CB-36X-1550
Image Sensor 5.0MP 1/2.8"  CMOS Sensor (Hi3516E V300 + SONY IMX335
Effective Pixels   1920P (2592 x 1944)
Minimum Illumination Color: 0.01Lux@F1.2(AGC ON), B/W: 0.001Lux@F1.2(AGC ON)
Lens  4.6- 167mm Motorized Auto Focus ICR 36X Optical Zoom Lens
Electronic Shutter  Auto / 1/25S - 1 / 10000S adjustable
Aperture Value F1.6 ~ F2.8
View of Angle  H: WIDE 54.8°, TELE 3.4°
V: WIDE 68.5°, TELE 4.2°
D/N  Auto, Dual IR-Cut Filter
BLC / White balance  BLC: On/Off, AWB
DNR 2D + 3D DNR
WDR DWDR
SNR More than 52 dB
Video Encoding  H.265+ , H.265 Main Profile / H.264 High Profile / H.264 Main Profile / H.264 Baseline Profile
Video Compression  H.265 / H.264 / M-JPEG
Max. Resolution  Main Stream: 5MP: 2560*1920@25/30fps, 2560*1440@25/30fps, Sub Stream: 704*576@25/30fps
Bit Rate  128Kbps ~ 12Mpbs
Audio Encoding  G.711A (64Kbps) / PCM
LAN Ports  RJ45*1, 10M / 100M
Network Protocol  HTTP, TCP / IP,  IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHC, DNS, IP Filter, PPPOE, DDNS, FTP
Protocol  ONVIF 2.6 / CGI / GB28281
Software Control  IE, CMS, Management Platform
Storage (Optional) One SD / SDHC card
Mobile View (Optional)  Support Windows, Symbian, iPhone Platform Smartphone
Horizontal Rotation Range  0-360°
Tilt Rotation Range 0-93°
Horizontal Rotation Speed 0-400°/s
Tilt Rotation Speed 0-90°/s
Auto Flip  Horizontal 180° , Vertical 180°
A-B Scan  User Programmable
A-B Scan Speed  0-64 Levels Setting Available
Dwell Preset  2-60s Interval Available
Preset Points  220
Guard Tours  8 Groups
Guard Points Max. 16 Points, Dwell Time user selectable
PWR On Action  Memory / Pattern 1 / Tour 1 / 360° Scan / A-B Scan / Preset 1-8 / None
Park Time  0-60 Minutes
3D Location  Support (DH-SD1)
Time Scheduling Function  8 Tasks
Privacy Mask  Support
Operation Menu  Multiple Languages for OSD Menu
Motion Detection  Intelligent Multiple Detection Zones
Pan / Tilt Position Display  Support
Auto Control IR LED PWM
Ambient Light Detection  IR Illumination on 1-9 Grades Selectable
IR Range  8 x ¢16 Array IR Led, 150M
Communication Protocol  Pelco-D, Pelco-P
Baud Rate  1200 / 2400 / 4800 / 9600bps (Default: 2400bps)
Operating Temp. Indoor: 0 ~ 40°, Outdoor: -40°~ 60℃
Humidity  ≤ 95% Non Condensing
Power  AC / DC15-28V ≤ 2A
Power Consumption  < 20W
Lighting Protection  Transient Voltage 6000V
Weight  4.6kg (N.W.), 6.2kg (G.W)
Weatherproof  IP66
Certification  CE / FCC / RoHS
